Cimbali

Cimbali M39 M39GT Wassereinlauf Flowmeter Manometer Ablauf

Drawing number 8281681

Under the exploded drawing you can order individual items.
If your article is not listed, please use the following form and enter the desired position numbers.

Request for unlisted item numbers.

Pos.:Image:Description:Qty.:
0faema kaltwasserblock korpus8112827
Faema Kaltwasserblock Korpus
83,97 €

excl. Shipping costs
Delivery time 4-6 weeks
2expansion valve8064256
EXPANSION VALVE
31,00 €

excl. Shipping costs
Delivery time
is determined
3silikonschlauch o 6x10 shore 60 100 m8073974
SILIKONSCHLAUCH ø 6x10 SHORE 60 - 100 m
830,06 €

excl. Shipping costs
Delivery time
is determined
3silikonschlauch o 6x10 shore 60 5 m8141608
Silikonschlauch ø 6x10 SHORE 60 - 5 m
22,61 €

excl. Shipping costs
immediately available, 2 available
10expansion valve8007058
EXPANSION VALVE
79,44 €

excl. Shipping costs
immediately available, 7 available
11blind gasket8064357
BLIND GASKET
6,31 €

excl. Shipping costs
Delivery time
is determined
14o ring 03043 epdm8001575
O-RING 03043 EPDM
0,89 €

excl. Shipping costs
immediately available
16nichel pl t fitting8022451
NICHEL-PL.T-FITTING
3,47 €

excl. Shipping costs
immediately available, 14 available
20drain pipe8006897
DRAIN PIPE
11,08 €

excl. Shipping costs
immediately available, 3 available
21silikonschlauch o 6x10 shore 60 100 m8073974
SILIKONSCHLAUCH ø 6x10 SHORE 60 - 100 m
830,06 €

excl. Shipping costs
Delivery time
is determined
21silikonschlauch o 6x10 shore 60 5 m8141608
Silikonschlauch ø 6x10 SHORE 60 - 5 m
22,61 €

excl. Shipping costs
immediately available, 2 available
22volumetric flowmeter gicar8006952
VOLUMETRIC FLOWMETER GICAR
100,60 €

excl. Shipping costs
Delivery time
is determined
22flowmeter durchflussmengenzaehler8097524
Flowmeter Durchflussmengenzähler
67,71 €

excl. Shipping costs
immediately available, 1 available
23flowmeter fitting cimbali faema8229591
Flowmeter Fitting Cimbali - Faema
28,67 €

excl. Shipping costs
Delivery time
is determined
24flache dichtung ptfe o 11x6 5x1 5 mm8103742
Flache Dichtung PTFE ø 11x6,5x1,5 mm
4,26 €

excl. Shipping costs
immediately available, 8 available
27magnetventil ode 2 wege o 1 8 quot 24vac8088818
Magnetventil Ode 2 WEGE ø 1/8" 24VAC
51,87 €

excl. Shipping costs
Delivery time
is determined
28t fitting8005755
T-FITTING
9,14 €

excl. Shipping costs
immediately available, 1 available
33schlauch ptfe o 2x4 mm 10 m8146546
SCHLAUCH PTFE ø 2x4 mm - 10 m
38,51 €

excl. Shipping costs
Delivery time
is determined
35non return valve spring o 6 5x20 mm8003676
NON-RETURN VALVE SPRING ø 6.5x20 mm
2,56 €

excl. Shipping costs
immediately available, 11 available
39inlet tap lever8002800
INLET TAP LEVER
17,86 €

excl. Shipping costs
Delivery time
is determined
42o ring or 02068 epdm8018526
O-RING OR 02068 EPDM
1,51 €

excl. Shipping costs
immediately available
43tap spring guide8003678
TAP SPRING GUIDE
4,47 €

excl. Shipping costs
immediately available, 7 available
45gasket orm 0057 19 viton green8002123
GASKET ORM 0057-19 VITON GREEN
1,20 €

excl. Shipping costs
immediately available, 12 available
46pump pressure gauge8003522
PUMP PRESSURE GAUGE
26,44 €

excl. Shipping costs
immediately available, 1 available
48o ring 02093 epdm8001639
O-RING 02093 EPDM
1,00 €

excl. Shipping costs
immediately available
49non return valve8063876
NON-RETURN VALVE
36,59 €

excl. Shipping costs
Delivery time
is determined
50non return valve spring o 6 5x20 mm8003676
NON-RETURN VALVE SPRING ø 6.5x20 mm
2,56 €

excl. Shipping costs
immediately available, 11 available
51faema tap spring guide8003675
Faema TAP SPRING GUIDE
2,96 €

excl. Shipping costs
immediately available, 13 available
52pin spring o 14x23 mm8003674
PIN SPRING ø 14x23 mm
3,17 €

excl. Shipping costs
immediately available, 13 available
53inlet valve8007056
INLET VALVE
30,08 €

excl. Shipping costs
Delivery time 4-6 weeks
55o ring 0040 20 epdm8036617
O-RING 0040-20 EPDM
0,84 €

excl. Shipping costs
immediately available
56water filter o 9 mm8001029
WATER FILTER ø 9 mm
1,43 €

excl. Shipping costs
immediately available
572 way solenoid valve lucifer 24v 50 60hz8062603
2-WAY SOLENOID VALVE LUCIFER 24V 50/60Hz
112,79 €

excl. Shipping costs
Delivery time
is determined
57magnetventil ode 2 wegen 24vac 8w8088826
MAGNETVENTIL ODE 2-WEGEN 24VAC 8W
49,80 €

excl. Shipping costs
Delivery time
is determined
58schraube zylinderkopf innensechskant vollgewinde edelstahl m4x10 a2 70 din 9128061180
Schraube Zylinderkopf Innensechskant Vollgewinde Edelstahl M4x10 A2-70 Din 912
0,67 €

excl. Shipping costs
immediately available

If your article is not listed, please use the following form and enter the desired numbers.

Request for unlisted item numbers.
